Epoxy Resins and Steel Powders

A mixture of epoxy resins and steel powders that strongly adheres to many materials such as steel, cast iron, and other metals, as well as concrete and certain hard plastics.

It is safely used for:

• Bonding broken machine parts,
• Filling casting defects and voids,
• Repairing and bonding punctured tanks, containers, and pipes,
• Coating and protecting damaged or worn metal surfaces due to friction.

Product Features

• Easily applicable to vertical surfaces.
• Bonds to aluminum, steel, and various other metals, as well as concrete.
• Can be machined on metallic surfaces.
• Provides rust-proof repairs.
• Resistant to chemicals, acids, bases, solvents, and alkalies.

Technical Information

• Color: Gray
• Mix Ratio (Hardener to Resin): By weight 9:1 - By volume 2.5:1
• Mix Viscosity: Paste
• Working Time for 500g at 24°C: 45 minutes
• Cure Time: 16 hours
• Initial Cure Time: 10–12 hours
• Solids by Volume: 100%
• Specific Volume: 430 cm³/kg
• Specific Gravity: 2.33 g/cm³
• Curing Shrinkage: 0.0006 cm/cm
• Shore D Hardness: 85
• Adhesive Shear Strength: 19.3 MPa
• Tensile Strength: 22.2 MPa
• Compressive Strength: 57 MPa
• Flexural Strength: 38.6 MPa
• Elastic Modulus: 1896 MPa
• Coefficient of Thermal Expansion: 86 × 10⁻⁶ °C⁻¹
• Thermal Conductivity: 1.37 × 10⁻³ cal·cm/sec/cm²·°C
• Dielectric Strength: 1181 volts/mm
• Dielectric Constant: 67.5
• Maximum Operating Temperature: Wet: 49°C, Dry: 120°C
• Coverage (per coating): 860 cm²/kg @ 5 mm

Application Method

The application surface must be clean, sanded, preferably lightly roughened, dry, and rust-free to ensure proper adhesion. Sanding is the ideal preparation method. Afterward, the surface should be cleaned with a suitable degreasing solvent and the bonding process should be completed without allowing the surface to reoxidize.

Please refer to the mixing ratio chart provided inside the product packaging for the correct ratios of resin and hardener. Add the hardener to the resin and mix thoroughly for about 4 minutes until a homogeneous mixture is achieved. (For Alcon 5 Minute SF product, curing begins within 5 minutes, so mixing should be completed in 1–2 minutes.) Mix using both circular and upward movements.

For paste types, apply the mixture onto the prepared surface with a putty knife. For liquid types, first, apply a thin coat with a brush, then pour the remaining liquid slowly along the edges of the mold cavity to avoid air bubbles. Spread the mixed material over the repair area and work it firmly into the substrate to ensure maximum surface contact. Plastic Steel Putty (A) fully cures within 16 hours and can then be machined, drilled, or painted.

Applications

A mixture of epoxy resins and steel powders that strongly adheres to various metals like steel, cast iron, and concrete, as well as other hard materials.

Warnings

Harmful to the environment.
